- Capacitive multi-touch screen, more sensitive touch, easy to use;
- Built-in self-developed R2000 ultra-high frequency RFID radio frequency module, with 3dbi antenna, high integration, strong reading performance, and the reading distance can reach up to 5 meters;
- Android (Android) 9.0 operating system industrial-grade handheld terminal, providing a good user experience;
- Industrial-grade handheld terminal using quad-core 64-bit Coretex-A53 high-speed processor, with strong performance and far ahead hardware parameters.
Basic parameters
| Overall size |
159mm×75mm×125mm (including handle) |
| Complete machine weight |
|
| Display |
5.7-inch IPS high-definition screen, resolution 720*1440 |
| Touchscreen |
Corning Gorilla industrial multi-touch capacitive screen |
| Expansion Slot |
1 SIM card slot, 2 PSAM card slots and 1 MicroSD(TF) card slot |
| Communication interface |
Type-C USB x 1, support OTG function |
| Audio |
Speaker (mono), microphone, earpiece |
| Indicator light |
Network indicator, charging indicator |
| Keyboard |
Power button, volume +/- button, scan button x 2, handle scan button x 1 |
| Rear camera |
8 million pixel camera with flash and auto focus |
| Front camera |
200W pixel color camera |
| Flashlight |
Low power consumption LED lighting, emergency use |
| GNSS |
Support GPS, Galileo, Glonass, Beidou |
Performance parameters
| CPU |
Octa-core 64-bit Coretex-A53 |
| Memory Capacity |
RAM: 3GB ROM: 32GB |
| Operating System |
Android9.0 |
| Extended memory |
Support 128GB Micro SD card |
Data communication
| 4G |
TD-LTE Band38/39/40/41，FDD-LTE Band1,3,4,7,8,12,20 |
| 3G |
WCDMA (850/900/1900/2100MHz) |
| 2G |
GSM (850/900/1800/1900MHz) |
| WIFI |
2.4GHz/5GHz, support IEEE 802 a/b/g/n/ac protocol |
| Bluetooth |
Support Bluetooth 2.1+EDR/3.0+HS/4.1+HS |
Barcode collection (optional)
| 2D scanning engine |
Honeywell N3603 |
| Support 2D barcode type |
PDF417,Micro PDF417,GS1 Composite,Aztec Code,Data Matrix,QR Code,Micro QR Code,
MaxiCode, Hanxin Code, etc. |
Ultra High Frequency (UHF) Index
| Module scheme |
M2210 module, based on Impinj Indy R2000 |
| Supported bandwidth |
840-960MHz (customizable) |
| Protocol Standards |
EPC C1 GEN2/ISO 18000-6C |
| Antenna parameters |
3dBi circular polarized antenna |
| Output power |
5dBm-27dBm |
| Reading distance |
0-5 meters |
| Reading speed |
400tags/s (reading speed and distance are related to the tag and the actual environment) |
Work environment
| Operating temperature |
-20℃～55℃ |
| Storage temperature |
-40℃～70℃ |
| Relative humidity |
5%RH～95%RH(non-condensing) |
| Drop Spec |
In the operating temperature range, the 6 sides can withstand a height of 1.2 meters
30 impact drops to concrete floors |
| Scroll Specifications |
Consecutive rolling 500 times 0.5m, 6 contact surfaces after rolling
Still running stably |
| Protection class |
Host IP66 |
Battery performance
| Battery Capacity |
5000mAh lithium polymer battery |
| Standby time |
Off wireless communication and other functions can stand by for 350 hours |
| Charging time |
The charging time is 3-4 hours, using the standard power adapter and data cable |
